Zipato Z-Wave Flood Multi-Sensor (PH-PAT02.US)

../../../_images/zipato_flood_multi.jpg

Brief information

  • Detects water to alert you to flooding, leaks
  • Measures room temperature and humidity
  • Works with any Z-Wave controller
  • Built-in tamper protection
  • Automatic low battery alerts

How to add to VENUS app

1. Activation
  • Press “Add button” (button ‘+’) in app
  • Press the tamper key three times within 1.5 seconds
  • Wait for VENUS scan & detect this device and inform in app
2. Reset before adding
  • Press “Add button” (button ‘+’) in app
  • Press the tamper key three times within 1.5 seconds to reset
  • Press the tamper key three times within 1.5 seconds once again to add
  • Wait for VENUS scan & detect this device and inform in app

How to add/remove associated device(s) to

This device supports 2 association group with max supported 8 nodes.

To add associated device(s) to this device, below action is required:

  • Add z-wave notified-devices (which will be associated to this sensor) to VENUS
  • Select Associate button and then select notified-device(s) to add
  • Wake-up this sensor: Press the tamper key three times within 1.5 seconds
  • If successful, pop-up notification displays in VENUS app

To remove associated device(s) from this sensor, below action is required:

  • Select Associate button and then select notified-device(s) to remove
  • Wake-up this sensor: Press the tamper key three times within 1.5 seconds
  • If successful, pop-up notification displays in VENUS app

Configuration description

  1. Operation mode

    Bit setting.

    Available setting

    Apply all bits: 1 - disable, 0 - enable

    Bit 0: Flood function

    Bit 3: Temperature type (0: Fahrenheit, 1: Celcius)

    Bit 5: Temperature function
    Default setting 0

  2. Multi-sensor function switch

    Bit control setting. Setting bit #6

    Available setting

    0 - Enable huminity report

    1 - Disable huminity report
    Default setting 0

  3. Customer function

    Available setting

    Apply all bits, 1: disable, 0: enable

    Bit 3: Disable function to send BASIC OFF (trigger to associated device off) after flood event cleared

    Bit 4: Notification type - 0: Notification report, 1: Sensor binary report

    Bit 5: Multi CC in auto report selection

    Bit 6: Battery report selection
    Default setting 0

  4. Auto report battery interval

    Interval time to device send battery information

    Available setting

    0 - Turn off auto report function

    1 ~ 127: Interval time (in ticks - tick is defined as below)
    Default setting 12

  5. Auto report temperature interval

    Interval time to device send battery information

    Available setting

    0 - Turn off auto report function

    1 ~ 127: Interval time (in ticks - tick is defined as below)
    Default setting 12

  6. Auto report huminity interval

    Interval time to device send battery information

    Available setting

    0 - Turn off auto report function

    1 ~ 127: Interval time (in ticks - tick is defined as below)
    Default setting 12

  7. Auto report flood interval

    Interval time to device send battery information

    Available setting

    0 - Turn off auto report function

    1 ~ 127: Interval time (in ticks - tick is defined as below)
    Default setting 12

  8. Tick interval used in auto report

    Tick interval can be set by user to configure time for auto report function.

    Available setting

    0 - Turn off all auto report functions

    1 ~ 255: Interval time (in minutes)
    Default setting 30

Factory reset

  • Press the tamper key four times within 1.5 seconds and hold it until LED lights up.
  • After 3 seconds the LED will turn OFF, and after that you should release the tamper key within 2 seconds.
